DL-1512M

Double Column Machining Center

Mold series

inquiry

Specification

XYZ linear guide ways	Roller type
Distance between Two Columns	1500 mm (59.1")
X travel	2100 mm (82.7")
Y travel	1200 mm (47.2")
Z travel	800 mm (31.5")
Spindle Nose to Table Surface	150~950 mm (5.9"~37.4")
Table size	2000x1100mm (78.7"x43.3")
T-slot (Q'ty x Size x Dist)	7x22x150 mm
Table Load Capacity	4000 kgs

Spindle Transmission	Direct type
Spindle Taper	BT40
Spindle Speed	10000rpm (DL-3112P) 15000rpm (DL-3112M)
ATC Capacity	24 tools
Spindle Motor	11/15 Kw

Rapid Feedrate (XYZ)	20/20/20 M/min
Floor space	443 x 750 x 386 cm
Machine Weight	15,500kgs

The manufacturer reserves the right to modify the design, specifications, mechanisms, etc. to improve the performance of the machine. Specifications are subject to change without notice.
