5 Axis Machining Center
Vertical Type


CNC Control


X travel

1,020 mm (40")

Y travel

610 mm (24")

Z travel

510 mm (20")

Spindle nose to table surface

100~610 mm (3.9"~24")

Table Diameter

Ø 350 mm (13.8")

T-slot (Q'ty x Size x Dist)

8x12x45 mm

Table Load Capacity

200 kgs (Horizontal)

200 kgs (Tilting)

A Axis Tilting Range


C Axis rotating Range


Spindle Transmission

Direct type

Spindle Taper


Spindle Speed

12000rpm (opt. 15000rpm)

Spindle Motor

7.5/11 Kw

Rapid Feedrate (XYZ)

36/36/36 M/min

ATC Capacity

24 tools

Max Tool Diameter

Full:  Ø 75 mm (3")

Next empty: Ø 150 mm (5.9")

Floor space

350x245x335 cm

Machine Weight

8,500 kgs

The manufacturer reserves the right to modify the design, specifications, mechanisms, etc. to improve the performance of the machine. Specifications are subject to change without notice.
