VF-1000

High Speed Bridge Type Machining Center

VF series

inquiry

Specification

XYZ linear guide ways	Roller type
X travel	1020 mm (40.2")
Y travel	610 mm (24")
Z travel	510 mm (20")
Spindle nose to table surface	150~660 mm (5.9"~26")
Table Size	1100x600 mm (43.3"x23.6")
T-slot (Q'ty x Size x Dist)	5x18x100 mm
Table Load Capacity	1000 kgs
Spindle Transmission	Direct type (opt. Build-in)
Spindle Taper	BT40
Spindle Speed	12000rpm(opt. 15000rpm /24000rpm)
ATC Capacity	24 tools
Spindle Motor	7.5/11 Kw
Rapid Feedrate (XYZ)	36/36/36 M/min
Dimensions	3555 x 2437 x 3560 mm
Machine Weight	8500 kgs

* Spinlde motor power depends on motor selection

The manufacturer reserves the right to modify the design, specifications, mechanisms, etc. to improve the performance of the machine. Specifications are subject to change without notice.
