| Travel | ||
|---|---|---|
| X travel |
1000 mm |
|
| Y travel | 800 mm | |
| Z travel | 900 mm | |
| Spindle center to work table surface | 25~825mm | |
| Spindle nose to work table center |
150~1050 mm |
|
| Table | ||
| Table surface to floor | 1160 mm | |
| Table size |
630×630 mm |
|
| T-slot/Bolt Spec. |
24-M16×P2.0 |
|
| Table Load Capacity | 1200 kgs | |
| Index precision | 1° | |
| Spindle | ||
| Spindle Taper | BT50 | |
| Spindle Speed |
6000 rpm |
|
| Feedrate | ||
| Spindle moter(cont/30 min) | 11/15 kw | |
| 3-axes cutting feedrate | 1~10000 mm/min | |
| 3-axes rapid feedrate | 36 m/min | |
| 3-axes min. setting unit | 0.001mm | |
| ATC | ||
| Tools | 24 tools | |
Note: Specifications are subject to change without further notice.
